Open Version Platinum Series - 4 Sided Moulders Leadermac

LMC-623P-1

With LMC Type Quick Release Spindle Nut and Easyset

Electric Diagram 623P With Quick Release Spindle Nut and Easyset Platinum Series Indowood

Spindle Diagram

Feed speed : 6 – 36 m/min
Feed motor : 7.5 HP/inverter
Spindle : 7200 rpm

Quick Release Spindle Nut

Compatible with standard spindle, fast, easy operation, and user-friendly

Easyset

SCHNEIDER 10.1” HMI (Memory 200sets)
2NC controls for 3rd spindle (radial) 4th & 5th spindle (radial) – moving together
1 NC control for the height of the feedbeam

Technical Data

LMC-623P-1 Platinum Series
Min. working width	15 mm
Max. working width	230 mm (with a tool cutting circle of 163 mm)
Min. working thickness	10 mm
Max. working thickness	150 mm (with a tool cutting circle of 163 mm)
Min. length of single work piece	800 mm
Min. length of work piece when feed consecutively	300 mm
1st bottom spindle	10 HP, allowable cutting circle (125 - 160 mm)
2nd right spindle	10 HP, allowable cutting circle (112 - 200 mm)
3rd left spindle	10 HP, allowable cutting circle (112 - 200 mm)
4th top spindle	15 HP, allowable cutting circle (112 - 200 mm)
5th top spindle	15 HP, allowable cutting circle (112 - 200 mm)
6th bottom spindle	15 HP, allowable cutting circle (112 - 200 mm)
up and down motor	¾ HP x 1
Spindle diameter	40 mm

Standard Features

Sound and safety enclosure.
– The entire machine is covered to reduce noise and safety working environment.
Harden chromed for entire feeding table.
– 0.3 mm harden chromed on its surface to last its serving life.
3 Stage pressure setting of feed roller.
– Pneumatic roller pressure compensates for large variances in work piece thickness. The max. air pressure setting is 6 bar.
Auto oil lubrication for feeding table.
– To supply oil on the 1 point of feeding table with timer control.
2 meter infeed table.
– Adjustment range for infeed table and edge-jointing fence is 10 mm
– Infeed fence with reference engraving
– Without hardened chrome for infeed fence and entire fence.
One piece full case iron body.
– Heavy duty element made of high quality cast metal with optimized vibration absorption characteristics are the best for the smooth running feedwork and spindle performance.
Power driven upper roller steel rollers before top spindle, rubber rollers after top spindle under standard spindle arrangement and 3 units of bottom roller are equipped with power driven roller on the feed table.
– Both upper and bottom feed driven by universal joint drive with no chains prevent stock free, more robust, low maintenance, longer service life and more accurate.
High precision spindle with the high speed bearing.
Documentation
– Maintenance manual, operation manual, electrical diagrams and parts list.
Cutter tool-1st spindle with edge reference cutter and TCT solid cutter and other spindle come with TCT solid cutter.
Tool box.
Without CE standard.
The cover of machine with hooks for lifting the machine.
Adjustment range of vertical spindle (axial) max. 40 mm.
Adjustment range of horizontal spindle (axial) max. 20 mm.
