*Machine picture shown is reference only
HP290
Computer Panel Saw (Front Feeding) Machine
Manual main blade dismantle
Chrome coated steel table
HOLD control system
Optional main saw servo lifting
Specification HP290 Computer Panel Saw Front Feeding Machine
| Model | HP290 |
|---|---|
| Feeding | Front feeding |
| Sawing length | 2900 mm |
| Sawing width | 2900 mm |
| Max. saw blade height | 120 mm intelligent lifting |
| Main saw blade | 450 x 4.4 / 3.2 x 75 x 72T / 105 |
| Scoring saw blade | 160 x 4.3 / 3.2 x 45 x 24T |
| Saw carrier forward speed | 5-100 m/min |
| Saw carrier return speed | 0 - 100 m/min |
| Pusher forward speed | 0 - 100 m/min |
| Pusher return speed | 0 - 100 m/min |
| Side pressure device | Pneumatic align panel |
| Main saw motor power | 15 kW, (18.5 kW optional) |
| Scoring saw motor power | 2.2 kW |
| Saw carrier servo motor | 1.8 kW |
| Pusher motor power | 1.8 kW |
| Gripper quantity | 7 pcs |
| Blower power | 2.2 kW |
| Rear feeding table size | - |
| Packing size | 5200 x 1150 x 1900 mm 4100 x 920 x 1000 mm |
| Machine overall size | 6750 x 5200 x 1850 mm |
| Weight | 4200 kg |
| Min. panel size | 30 x 30 mm |
| Total power | 23.5 kW |
