*Machine picture shown is reference only
HD-620J
Automatic Edge Banding Machine
Standard Process
- Pre-milling
- Gluing
- Pressing
- End Cutting
- Rough Trimming
- Fine Trimming
- Scraping
- Buffing
Standard Configuration
Control System: Operation Flexible
Electric Press Beam Lifting
Pre-milling Device (Max Removing Thickness ≤ 1 mm)
Buffing Device
2.2 kW Power Harden Gear Reducer
EVA Gluing Device
Pressing
End Cutting Device
Rough Trimming Device
Fine Trimming Device
Scraping Device
Unique Design: Rubber-coated Wheel
Optional Configuration
Liquids Previous Premilling
Liquids for Cleaning at The End
Quick Melt Device
Specification of HD620J
| Model | HD620J |
|---|---|
| Electric lifter | ✓ |
| Total power | 14.2 kW |
| Dimensions | 6000 x 900 x 1700 mm |
| Feeding speed | 14/20/23 m/min |
| Edge banding thickness | 0.4 - 3 mm |
| Panel thickness | 10 - 60 mm |
| Panel length | ≥ 120 mm |
| Panel width | ≥ 80 mm |
| Working pressure | 0.6 Mpa |
| Min. panel size | 120 x 80 mm |
Discover More Basic Edge Bander Machine
*Machine picture shown is reference only
HD620
Automatic Edge Banding Machine
The HD620 is a reliable automatic edge banding machine designed for clean, fast, and precise results perfect for small to mid-sized production environments.
*Machine picture shown is reference only
HD621
Automatic Edge Banding Machine
The HD621 is an advanced automatic edge banding machine engineered for smooth and accurate edge finishing ideal for medium to large-scale woodworking production.
*Machine picture shown is reference only
HD621J
Automatic Edge Banding Machine
The HD621J is a high precision automatic edge banding machine designed to improve efficiency and ensure top quality edge finishing for furniture manufacturing.
