PCY3000-3 / PCY4000-4 / PCY5000-5
Circular Sawmill with Log Carriage
This product is developed to has a high cutting efficiency. The saw blade is made of hard alloy saw blade and easy to grind. The power can be electric or diesel. The machine is free of basic installation and easy to operate.
PCY3000-3 / PCY4000-4 / PCY5000-5 Video
Kunjungi Youtube channel PT. Alpha Utama Mandiri untuk melihat berbagai macam update konten video mesin-mesin perkayuan terbaru.
Specification PCY3000-3 / PCY4000-4 / PCY5000-5
| MODEL | PCY3000-3 | PCY4000-4 | PCY5000-5 |
|---|---|---|---|
| Max. Sawing Wood Diameter | 500 mm | 500 mm | 500 mm |
| Motor Power | 30 kW | 30 kW | 30 kW |
| Forward/Backward | Manual | Manual | Manual |
| Manual Carriage Stake Quantity | 3 | 4 | 4 |
| Carriage Length | 3000 mm | 4000 mm | 5000 mm |
| Max. Sawing Wood Length | 4000 mm | 5000 mm | 6000 mm |
| Rail Length | 9000 mm | 11000 mm | 11000 mm |
| Machine Weight | 1500 kg | 1800 kg | 2000 kg |
Options:
- Change to electric foward and backward
- Change to 40HP diesel engine
