Stroke Sander Wire Brush
Specification Stroke Sander Wire Brush
| Mode | Stroke Sander Wire Brush |
|---|---|
| Operating voltage | 3 phase - 380 V +- 5%/50 Hz |
| Working size (L x W x H) | 2600 x 1000 x 300 mm (option 2600 x 2000 x 300 mm) |
| Width wire and fiber brush | About 210 |
| Type sander wire brush | Filament 0.35 mm (option filament 0.3 mm, 0.4 mm, 0.5 mm) K180 (Option K120, K320) |
| Fiber sanding unit - Wheel ⌀200 / 210 mm | 1450 rpm |
| Fiber sander motor | 1.1 kW |
| Shaft diameter | 2 (50.8 mm) |
| Fiber move speed | 20.7 m/min, 50 Hz |
| Fiber move speed motor | 0.37 kW (200 W) |
| Dust extraction hood | ⌀60 mm |
| Air volume / Dust extraction | 1008 m3/h |
| Size of machine (L x W x H) | 3570 x 2010 x 1600 mm (Option 3570 x 4070 x 1600 mm) |
| Machine net weight | 630 kg (Option 720 kg) |
| Total power | 1.67 kW |
