SR-RP1300
Wide Belt Sander
The high and new technology cast the highest level of precision in the same rank
Incredible sanding effect and durability
Highlights
- The whole stability of models with high rigidity thick wall and high strengthmachine have improved greatly than ever conventional models.
- There are 5 innovative structures and 18 upgrade configurations verifing the “best of breed” technologies in order to achieve the optimum properties
Spesifikasi SR-RP1300
| Model | SR-RP1300 |
|---|---|
| Max. working width | 1300 mm |
| Min. working length | 580 mm |
| Working thickness | 3 - 110 mm |
| Feeding speed | 5 - 28 m/min |
| Total motor power | 62.92 kW |
| Motor for first unit | 30 kW (37 kW) |
| Motor for second unit | 22 kW |
| Feeding motor | 3.0 kW |
| Lifting motor | 0.55 kW |
| Motor for brush roller | 0.37 kW |
| Hardness of first roller | Steel roller |
| Hardness of second roller | 70 sh |
| Diameter of first roller | ø240 mm |
| Diameter of second roller | ø210 mm |
| Linear speed of first belt | 20 m/s |
| Linear speed of second belt | 18 m/s |
| Abrasive belt size | 1330 x 2200 mm |
| Working air pressure | 0.6 Mpa |
| Air consumption | 17 m³/h |
| Volume of dust collection device | 8200 m³/h |
| Overall dimensions | 2040 x 2650 x 2160 mm |
| Net weight | 3900 kg |
SR-RP1000
Wide Belt Sander
SR-RP700
Wide Belt Sander
- High rigidity and thermal stability
- Accuracy increased by 20% compared to conventional models
- Meet the diversified processing needs pursue cost-effective and present compact and intelligent application
- The shortest processing length can be adjusted to 200 mm
Outstanding -a new type of small giant- to meet the diversified parts sanding
Spesifikasi SR-RP 1000 | SER-RP 700
| Model | SR-RP1000 | SER-RP700 |
|---|---|---|
| Max. working width | 1000 mm | 700 mm |
| Min. working length | 470 mm | 400 mm |
| Working thickness | 3-160 mm | 3-160 mm |
| Feeding speed | 5-25 m/min | 4-18 m/min |
| Total power | 38.87 kW | 24.37 kW |
| Abrasive belt size | 1030 x 2200 mm | 730 x 1900 mm |
| Dimensions | 1795 x 2150 x 2080 mm | 1390 x 1680 x 1990 mm |
| Weight | 2300 kg | 1400 kg |
