- Available biomass pellet diameter from 6, 8, 10 to 20mm.
- The ring dies are made of special stainless steel to guarantee the production performance and the total lifetime; double layer design, easy to use and maintain.
- Fully automatic grease lubricating design, bottom reducer, and flipping reducers applied gear oil lubricating, reducing grease consumption.
Available Raw Materials






LD560A | LD700 | LD720 | LD850 | |
---|---|---|---|---|
Main power | 110 kW | 132kW (LD700) | 160 kW | 220 kW |
Unit capacity | 1-1.5 T/H | 1.5-2T/H | 2-2.5 T/H | 3-4T/H |
Pellet diameter | 6/8/10 mm (optional) | 6/8/10 mm (optional) | 6/8/10 mm (optional) | 6/8/10 mm (optional) |
Flipping motor | 1.5 kW | 1.5 kW | 2.2 kW | 3 kW |
Ring die inner diameter | 560 mm | 560 mm | 720 mm | 850 mm |
Ring die material | Heat processed alloy steel | Heat processed alloy steel | Hot processed alloy steel | X46Cr13 Stainless Steel |
Gear oil pump power | 1.1 kW | 1.1 kW | 1.5 kW | 2.2 kW |
Dust collector | 3 kW | 3 kW | 3 kW | 3 kW |
Grease type | Automatic oil pump | Automatic oil pump | Automatic oil pump | Automatic oil pump |
Gearbox cooling method | 80 W Brass Radiator | 80 W Brass Radiator | 100 W Brass Radiator | Brass Radiator Set, Air cooling |
Air colling power | 2.2 kW | 2.2 kW | 3 kW | 4kW |
Gross weight | 4,484 kg | 4,993 kg | 5,680 kg | 8,890 kg |
Overall dimension | 2500*1350*1900 mm | 2500*1350*1900 mm | 2680*1500*2100 mm | 2880*1730*2200 mm |
Mesin Produksi Pellet Kayu Sesuai Kebutuhan
Sesuaikan bahan dan kebutuhan mesin produksi pellet kayu ataupun pellet pakan ternak yang dengan kapasitas produksi.

Small Pellet Mill P Series
Untuk produksi pellet untuk pakan ternak.

Eco Grinder C Series
Untuk produksi pellet kayu dari jerami, kulit kacang, dll.
