*Machine picture shown is reference only
MRS-610M
Gang Rip Saw with 1 – 6 Powered Moving Saw
Dimension Diagram
Specification of MRS-610M
| Model | MRS-610M |
|---|---|
| Max. cutting thickness | 12" blade 75 mm 14" blade 100 mm |
| Number of movable saws | 4 (6 optional) |
| Max. material width of pass through | 1040 mm |
| Max. cutting width | 610 mm |
| Min. material length | 610 mm |
| Max. sawblade diameter | ⌀ 355 mm |
| Min. sawblade diameter | ⌀ 305 mm |
| Sawblade bore | ⌀ 90 mm |
| Saw arbor diameter | ⌀ 70 mm |
| Saw arbor speed | 4200 rpm (50 Hz) 4500 rpm (60 Hz) |
| Saw arbor motor | 50 , 60 , 75 , 100 or 125 HP |
| Feed motor | 5 HP |
| Variable feed speed | 8 - 60 m/min |
| Dust hole diameter | ⌀ 100 mm x 1 ⌀ 200 mm x 2 |
| Table height from floor | 855 mm |
| Table area | 2050 x 900 mm |
| Overall dimension | 2290 x 2630 x 1950 mm |
| Net weight | 5600 kgs |
Discover More Quick Rip System
*Machine picture shown is reference only
MRS-610M Quick Rip System
Movable Rip Saw with 2D Image Scanning System
MRS-610M offers high-speed and high efficiency performance with 2D image scanning and Quick Rip System. Designed to optimize wood cutting in real time with precision and minimal waste.
