MRS-340M + Skew
Optimizing Movable Rip Saw with 2D Image Scanning System
Video of MRS-340M + Skew
Machine Dimension of MRS-340M + Skew
Features of Optimizing Movable Rip Saw + Skew
- 100% American designed and developed scan system. Easy to operate, learn, update and maintain with iMac operating system
- Rip 4~6 lumbers per minute
- 7~10% increase in yield compare with conventional multiple rip saw.
- Uniquely designed auto skew system, which provides 2-3% yield more than original fixed fence.
- Our system allows customer to do simulation based on rip width, giving the best saw width combination to customer for material saving.
- Provide production report, which include yield, quantity, total length, and cubic meter, and allow user easily to manage production, control inventory, and calculate cost.
- Allow single person to operate the machine, and the operating position is out of harms way from kickbacks.
Accessories of MRS-340M + Skew
Air Loaded Pressure Rollers
The complete air loaded pressure rollers and the patented design hold down plate can ensure the stability when cutting wood, thus to achieve the board glue joint effect after ripping.
Anti Kickback Guarding System
Hardened steel anti kickback finger system (2 upper rows and 1 bottom row) are engineered for greater operator safety.
Mechanical Lubricator
- The mechanical oil supply design can avoid the risk of electronic failure and ensure that the feed chain is always oiled.
- The oil amount can be automatically adjusted according to the feed speed.
Specially Designed Feed Chain with Replaceable Surface Pads
Two replaceable surface pads are available
- Rubber surface pads that do not damage the wood surface.
- Forged surface pads for processing the board with rough surface.
Sleeve Type Multiple Rip Saw (Optional)
With optional accessory, the machine can be worked as sleeve type multiple rip saw.
Specification of MRS-340M + Skew
| Model | MRS-340M + Skew |
|---|---|
| Max. cutting thickness for movable saw mode | 14" → 100 mm 12" → 75 mm |
| Min. working length | 1.1 M |
| Max. working length | 3.6 M, 4.8 M |
| Movable saw traverse (from fixed saw) | 20 mm - 340 mm |
| Max. saw blade diameter | ⌀ 355 mm |
| Min. saw blade diameter | ⌀ 305 mm |
| Saw blade hole diameter | ⌀ 90 mm |
| Saw arbor diameter | ⌀ 70 mm |
| Saw arbor speed | 14" → 3800 rpm (50 Hz, 60 Hz) 12" → 4200 rpm (50 Hz), 4500 (60 Hz) |
| Saw arbor motor | 30 HP, 40 HP, 50 HP or 60 HP |
| Feed motor | 3 HP |
| Feed speed | 12 - 40 m/min |
| Hold down roller elevating motor | ½ HP |
| Saw arbor elevation motor | ½ HP |
| Dust suction hole diameter | ⌀ 100 mm x 1, ⌀ 200 mm x 1 |
