*Machine picture shown is reference only
HEK409
CNC Nesting Machine
Heavy duty machine frame
12 kW ATC spindle
12 tools linear ATC
Specification HEK409 CNC Nesting
| Model | HEK409 |
|---|---|
| Working size | 1220 x 2750 x 30 mm |
| Working strok | 1850 x 3500 x 260 mm |
| Idle speed | 80 m/min |
| Working speed | 12 - 25 m/min |
| Spindle power | 12.0 kW |
| Spindle speed | 18000 r/min |
| Operating voltage | AC 380V / 3 Ph / 50Hz |
| Drive system | Servo drive |
| Positioning structure | High precision single positioning cylinders + positioning stops |
| Table structure | Division vacuum suction table |
| Overall dimension | 4300 x 2800 x 3000 mm |
| Dust holes | Φ 150 / Φ 100 mm |
| Total power | 26 kW |
| Weight | 3.5 T |
