MJH1200E – MJH1500E
Combined with hydraulic automation technology, the heavy-duty hydraulic horizontal band sawmill realizes all-digital intelligent control. Chinese and English operating systems, automatic rotation, sawing, and cutting of large diameter wood, simple operation of equipment, precise cutting thickness, improves wood usage rate.
MJH1200E – MJH1500E Video
Kunjungi Youtube channel PT. Alpha Utama Mandiri untuk melihat berbagai macam update konten video mesin-mesin perkayuan terbaru.
STANDARD CONFIGURATION
Hydraulic chain rotation X 2
Touch screen sizing
Variable frequency speed adjustable foward / backward
Hydraulic wood clamp X 2
Hydraulic log stop pole X 4
Board automatic return hook
Hydraulic rotation clamping X 1
OPTIONS
Hydraulic plant roller axle X 1
Hydraulic wood adjuster X 1
Extend the rail length
log loading deck
Specification MJH1200E - MJH1500E
| MODEL | MJH1200E | MJH1500E |
|---|---|---|
| Max. Sawing Wood Diameter | 1200 mm | 1500 mm |
| Saw Wheel Diameter | 1000 mm | 1070 mm |
| Max. Sawing Wood Thickness | 400 mm | 400 mm |
| Standard Sawing Wood Length | 4500 mm | 4500 mm |
| Electric Motor Power | 37 kW | 45 kW |
| Up/Down Electric Motor | 2.2 kW | 2.2 kW |
| Forward/Backward Electric Motor | 3 kW | 3 kW |
| Band Saw Blade Width | 125-150 mm | 125-150 mm |
| Band Saw Blade Tension | Electric | Electric |
| Machine Length | 7000 mm | 7000 mm |
| Weight | 7000 kg | 8500 kg |
