HD876J
Advanced Edge Banding
Quick change buffing
Horizontal scraping
40 mm narrow end
Heavy duty lifting
Heavy duty steel press beam
Standard Process
- Releasing
- Pre-milling
- Heating lamp 1
- PUR changeover pot
- Pressing 1
- Heating lamp 2
- Pre-melting
- Upper gluing system
- Pressing 2
- Double rail three motor end cutting
- Fine trimming 1
- Fine trimming 2
- Four motor corner rounding
- Scraping 1
- Scraping 2
- Off cut
- Glue scraping
- Cleaning
- Buffing 1
- Buffing 2
Specification of HD876J
| Model | HD876J |
|---|---|
| Lifting | CNC lifting |
| Total power | 33 kW |
| Overall size | 10500 x 1000 x 1800 mm |
| Feed speed | 14 - 20 - 23 m/min |
| Tape thickness | 0.4 - 3 mm |
| Panel thickness | 10 - 60 mm |
| Panel length | ≥ 120 mm |
| Panel width | ≥ 40 mm |
| Working air pressure | 0.6 mpa |
| Min. panel size | 40 x 300 mm (corner rounding on) |
