SH80-300 / SH120-250 / SH160-250 / SH120-300 / SH160-300 / SH160-400
Double Spindle Panel Cutting Multiple Blade Rip Saw
SH80-300 / SH120-250 / SH160-250 / SH120-300 / SH160-300 / SH160-400 Video
Kunjungi Youtube channel PT. Alpha Utama Mandiri untuk melihat berbagai macam update konten video mesin-mesin perkayuan terbaru.
Specification Double Spindle Panel Cutting Multiple Blade Rip Saw Series
| MODEL | SH80-300 | SH120-250 | SH160-250 | SH120-300 | SH160-300 | SH160-400 |
|---|---|---|---|---|---|---|
| Max. Sawing Width | 300 mm | 250 mm | 250 mm | 300 mm | 300 mm | 400 mm |
| Max. Sawing Thickness | 80 mm | 120 mm | 160 mm | 120 mm | 160 mm | 160 mm |
| Min. Sawing Length | 600 mm | 500 mm | 500 mm | 600 mm | 600 mm | 600 mm |
| Motor Power | 15 kW x 2 | 22 kW x 2 | 30 kW x 2 | 22 kW x 2 | 30 kW x 2 | 37 kW x 2 |
| Saw Blade Diameter | 180 mm | 230 mm | 255 mm | 230 mm | 280 mm | 280 mm |
| Machine Weight | 1200 kg | 1800 kg | 2000 kg | 2500 kg | 2800 kg | 3000 kg |
