M3
Baby Feeder
Light Duty
Small, Lightweight, Economical and Versatile Patented 3-D Adjustable Arm Design
AF32
Junior Feeder
Light Duty
AF308
Cabinet Feeder
Medium Duty
Ideal for Cabinet Works and Combining Machine
AF04 | AF04L
Track Feeder
720 mm | 1050 mm Overarm
Medium Duty
Special for Shorter Piece or Extra Heavy Duty Work
Specification Light and Medium Duty Series
| Model | M3 |
|---|---|
| Horsepower | 94 W (⅛ HP), 1 phase |
| Rotation | Forward / reverse |
| Range of speeds | 2 - 12 m/min |
| Rollers | ⌀ 76 x 30 mm x 3 pcs |
| Roller suspension | 8.3 mm |
| Net weight | 10.5 kg |
| Gross weight | 12 kg |
| Carton for body | 560 x 280 x 230 mm |
| 20' container loading | 840 sets |
| Model | AF32 |
|---|---|
| Horsepower | 188 W (¼ HP), 1 or 3 phase |
| Rotation | Forward / reverse |
| Range of speeds | 50 Hz : 5 / 6.5 / 8 / 11 m/min 60 Hz : 6 / 8 / 10 / 13 m/min |
| Rollers | ⌀ 80 x 30 mm x 3 pcs |
| Roller suspension | 18 mm |
| Net weight | 33 kg |
| Gross weight | 35 kg |
| Carton for body | 580 x 580 x 280 mm |
| 20' container loading | 320 sets |
| Model | AF308 |
|---|---|
| Horsepower | 375 W (½ HP), 1 or 3 phase |
| Rotation | Forward / reverse |
| Range of speeds | 3 PH : 3 / 4.5 / 6 / 7.5 / 9 / 11.5 / 15 / 23 m/min 1 PH : 3 / 4.5 / 7.5 / 11.5 m/min |
| Rollers (belts) | ⌀ 100 x 50 mm x 3 pcs |
| Roller suspension | 24 mm |
| Net weight | 25 + 22 kg |
| Gross weight | 27 + 24 kg |
| Carton for body | 520 x 470 x 260 mm |
| Carton for stand | 770 x 230 x 260 mm |
| 20' container loading | 276 sets |
| Model | AF404 |
|---|---|
| Horsepower | 750 W (1 HP), 1 or 3 phase |
| Rotation | Forward / reverse |
| Range of speeds | 50 Hz : 4 / 8 / 10 / 20 m/min 60 Hz : 4 / 8 / 10 / 20 m/min |
| Optional speeds (with extra gear set) | 3 / 6 / 14 / 28 m/min |
| Rollers (belts) | 1118 x 12.7 mm x 3 pcs / synthetic rubber |
| Roller suspension | 20 mm |
| Net weight | 30 + 34 kg |
| Gross weight | 32 + 36 kg |
| Carton for body | 770 x 560 x 290 mm |
| Carton for stand | 770 x 320 x 290 mm |
| 20' container loading | 150 sets |
