DFS series cutter head shredder is a wood shredding machine that integrates the functions of a chipper and hammer shredder. It is used to process wood, branches, and other raw materials into sawdust or sawdust at one time. The feeding port is large, which is suitable for raw materials that cannot be processed by the hammer mill. It has many advantages such as small size, small footprint, low investment, high return, low energy consumption, high efficiency, easy use, and maintenance.
| Model | LDDFS-420A | LDDFS-420B | LDDFS-500B |
|---|---|---|---|
| Main power | 11 HP | 15 kW | 22 kW |
| Unit capacity | 500-800 kg/h | 500-800 kg/h | 800-1200 kg/h |
| Final material size | 6-12 mm | ||
| Blade Quantity | 12 PCs | 18 PCs | |
| Ideal moisture | 20% Woods | ||
| Inlet size | 200*200 mm | ||
| Electricity | 380V 50Hz 3Phases | ||
| Transmission | V-belt | ||
| Packing type | Firm plywood case | ||
| Gross weight | 595 kg | 360 kg | 600 kg |
| Overall dimension | 950*620*1140 mm | 1240*1000*1200 mm | 1300*450*570 mm |
